Wisdom Audio Sage Series C38
Available to Order
Contact UsThe horizontal sibling of the P38 — the MTM planar array rotated ninety degrees over four 6-inch woofers, 90 dB sensitive, 40 Hz to 20 kHz.
Product Details
Description
The C38 is the horizontal sibling of the P38, and the difference between them is smaller and more interesting than it looks. They share driver technology and are timbre matched, but the MTM planar array is rotated ninety degrees so that dispersion stays correct in the orientation the loudspeaker actually sits in.
That is the detail most horizontal centre channels get wrong. Turning a vertical design on its side narrows the horizontal dispersion exactly where a centre channel needs it widest, which is why so many centres sound correct in one seat and hollow in the next. Rotating the array rather than the cabinet solves it.
Four 6-inch high operating pressure woofers sit alongside, response runs 40 Hz to 20 kHz within 2 dB, and the enclosure is aircraft grade aluminium. Available in-wall as the C38i, on-wall as the C38m and free-standing as the C38, with two amplifier channels and outboard DSP required.
Featured Specs
Type
Point source, horizontal orientation
Drivers
MTM planar magnetic array and four 6-inch high operating pressure woofers
Frequency Response
40 Hz – 20 kHz, plus or minus 2 dB
Sensitivity
90 dB / 1 W / 1 m
Impedance
Planar 3 ohms · woofer column 3 ohms
Configurations
C38i in-wall · C38m on-wall · C38 free-standing
General Specs
Series
Sage Series
Type
Point source — in-wall, on-wall or free-standing, horizontal
Drivers
MTM planar magnetic array, four 6-inch high operating pressure woofers
Frequency Response
40 Hz – 20 kHz ± 2 dB
Sensitivity
90 dB / 1 W / 1 m
Impedance, Planar Section
3 ohms
Impedance, Woofer Column
3 ohms
Amplifier Channels Required
2
Processing
Outboard active crossover and DSP required
Enclosure
Aircraft grade aluminium throughout
Finishes
Custom colours and lengths on C38 and C38m, custom length grilles on C38i, anodized trim bezels
Finishes
