McIntosh PS1K Powered Subwoofer

Available to Order

$40,000

Contact Us

Powered subwoofer — two 13-inch LD/HP woofers, two 500W Class D amps (1,000W total), multi-layer carbon fiber cones, sealed box, parametric EQ.

Product Details

Description

The McIntosh PS1K is McIntosh's dual-driver powered subwoofer — a two-woofer, two-amplifier design that shares the same fundamental engineering as the PS2K flagship at half the driver and amplifier count. Two 13-inch woofers with the patented Low Distortion/High Performance (LD/HP) Magnetic Circuit Design, each driven by a dedicated 500-watt Class D amplifier, combine to deliver up to 1,000 watts of low-frequency energy. For rooms and systems where the PS2K would be more subwoofer than needed, the PS1K delivers the same core McIntosh subwoofer character at a more accessible scale.

The driver-side engineering carries over from the PS2K unchanged. Multi-layer carbon fiber cones with an integrated formed joint to the voice coil deliver the same rigidity and distortion characteristics. Extra-long voice coils and long-excursion suspensions extend linear capability. Nearly 1.5-inch-thick sealed enclosure baffle for cabinet rigidity, woofers stacked above the amplifier module with a power output meter showing total real-time output.

The DSP suite is identical to the PS2K: adjustable low-pass filters, high-pass filters, two-band parametric EQ for room correction, level control, and phase adjustment. Power Control integration with other McIntosh components. High-gloss black finish with carbon trim and aluminum base to complement the XRT2.1K and XRT1.1K visually.

Pair with McIntosh loudspeakers (XR-series, LCR80, or ML1 Mk II) to extend low-frequency response deeper than the mains can achieve alone, or use in a mid-tier home theater system for cinema LFE reproduction. Available at LMC — walk in during business hours or book ahead.

Featured Specs

General Specs

Configuration

Powered subwoofer — dual 13-inch woofers, dual 500-Watt Class D amplifiers, sealed-box enclosure. Same fundamental engineering as the PS2K flagship at half the driver/amp count

Total Power

1,000 Watts (2 × 500W Class D)

Driver Complement

Two 13-inch woofers per cabinet with patented Low Distortion/High Performance (LD/HP) Magnetic Circuit Design

Cone Technology

Multi-layer carbon fiber cones with integrated formed joint to voice coil — same construction as the PS2K flagship

Voice Coil

Extra-long voice coil, long-excursion suspension for extended linear capability

Enclosure

Sealed-box design (no port noise), nearly 1.5-inch thick baffle for structural rigidity

Woofer Layout

Vertically stacked atop the amplifier module with a power output meter showing total real-time PS1K output

DSP Features

Adjustable Low Pass Filters, High Pass Filters, Parametric EQ Filters, Level Control, Phase Adjustment — same DSP suite as the PS2K

Finish

High-gloss black with carbon trim and aluminum base — complements the XRT2.1K and XRT1.1K visually

Integration

Power Control for on/off from other McIntosh components; eco-friendly signal sensing for efficient power management; glide feet for hard floors and spikes for carpeting

Application

Mid-tier powered subwoofer for rooms where the PS2K would be more subwoofer than needed — pairs with McIntosh loudspeakers (XR-series, LCR80, ML1 Mk II) to extend low-frequency response, or with a mid-tier McIntosh cinema system for LFE reproduction
