Octave

Octave V 40 SE Integrated Amplifier

Available to Order

$5,750 (each)

Contact Us

The current entry Octave tube integrated — 2 x 40 W RMS and 50 W into 4 ohms, a direct descendant of the V 40 and V 50 models it replaces.

Product Details

Description

The Octave V 40 SE is the current entry-level integrated amplifier in Octave's range — a line-level integrated with 2 x 40 W peak output power that is a further development and direct descendant of the earlier V 40 and V 50 amplifier models. Powerful, clear bass fundamentals and captivating high-frequency resolution have earned the V 40 SE much respect — including the rare 'Stereoplay Highlight' award from Germany's Stereoplay magazine (issue 07-2009).

The V 40 SE output stage uses two power pentodes (Type 6550 JJ) per channel. Octave's BIAS Control and Monitoring System allows the use of other pin-compatible output tubes to match the amplifier to personal taste or benefit from newer tube types — KT 88, KT 90, KT 100, or 6550 tubes will operate at full 40Wpc, while 6L6, KT 66, KT 77, 5881, or EL34 pentodes can be substituted at lower power. Like all Octave amps, the V 40 SE is based on Octave's enhanced pentode configuration — the circuit that ensures absolute stability against unstable loudspeaker impedance. Impedance mismatch is without consequence; the V 40 SE is stable down to a 2-ohm load.

A single-impedance output transformer contributes significantly to this stability. The V 40 SE is a perfect amp for average-efficiency loudspeakers, but the exceptional signal-to-noise ratio of -110 dB at full power also makes it an ideal partner for high-efficiency loudspeakers. Cabinet 408 x 159 x 490 mm, weight 18.0 kg.

Standard Octave Power Management, Soft-Start Electronics, Protection System, Eco Mode, BIAS Setting and Display, Monitor/Record Output, HT Bypass, Pre-Out, and (Super) Black Box Connection. Silver or Black chassis. Available at LMC for audition.

Featured Specs

General Specs

Configuration

Line-level integrated amplifier — Octave's current entry into the range (successor lineage: V 40 → V 50 → V 40 SE)

Tube Configuration

4 x 6550 JJ standard; pin-compatible upgrades supported

Output Power

40 W RMS / 50 W into 4 ohms

Frequency Response

20 Hz – 70 kHz

THD

<0.1% at 10 W / 4 Ω

Signal-to-Noise

-100 dB / 40 W (spec: -110 dB / Full Power)

Inputs

5 x RCA (including HT bypass)

Outputs

1 x RCA record, 1 x regulated preamp output, 1 x loudspeaker

Dimensions

408 x 159 x 490 mm (WxHxD)

Weight

18.0 kg

Options

Black Box / Super Black Box power supply upgrade

Finishes

Silver or Black

Application

Octave's current entry integrated — perfect partner for average-efficiency loudspeakers, and via -110 dB S/N ratio, an ideal partner for high-efficiency loudspeakers too. Recipient of the 'Stereoplay Highlight' award (issue 07-2009)

Finishes
